Eeger Beever 2131 Brush Chipper

General

Height:  9’6″ (2.89 m)
Width: 7’7″ (2.31 m)
Length: 21’2″ (6.54 m)

Gross weight (approx., single axle): 11,000 lb (4,990 kg)
Gross weight (approximate, tandem axle):  12,200 lb (5,535 kg)
Suspension: Single Axle: (1) 10,000 lb Torflex (4,536 kg)
Suspension: Tandem Axle: (2) 8,000 lb Torflex (3,629 kg)

Infeed Opening: 36″ high x 59″ wide (91.4 cm x 149.9 cm)
Throat Opening: 20.5″ high x 31″ wide (52.1 cm x 78.7 cm)

Drum: 23.5″ wide x 37.375″ diameter (56.69 cm x 94.93 cm)

Engine: CAT, GM or Perkins
Horsepower: 147– 275 HP (109.6—205 kW)

Fuel capacity: 60 gallons (227.1 litres)
Hydraulic oil capacity: 41 gallons (155.2 litres)

Frame: 2″ x 6″ tubular (5.08 cm x 15.24 cm)

Tires: 235/75Rx17.5

Hitch: 2.5″ Pintle Ring (6.35 cm)

Equipment Highlights

23.5″ wide (59.7 cm) x 37.375″ (94.9 cm) diameter, four dual-edged knife staggered-pocket drum with removable knife holders, dual-sided, chambered air impeller system and controllable air flow vents

Dual horizontal feed wheels with TorqMax™ top feed wheel compression system, hydraulic lift assist and Variable Force™ constant hydraulic down pressure system with additional manually applied hydraulic down pressure at the valve handle

Live hydraulic system including: ball valve, pump, motor, and valve bank with additional preplumbed valve section for installation of an aftermarket winch package

360° manual height-adjustable discharge

Direct-drive bottom feed wheel

Options

• ChipSafe® Operator Safety Shield
• Winch Package: heavy-duty, 5,000 lb (2268 kg) pull capacity with rope and 10′ (3 m) chafe guard
• Custom Paint and Logo Packages
• Bottom Bump Bar
• Hydraulic Swivel Discharge
• Cone Holder
• Spare Tire and Mount
• Folding Infeed Tray
• Flow Control
• Axle Options Available
• Infeed Curtain
• Strobe Light
• Pusher Paddle
• Front and Rear Stabilizers
