Boxer 700HDX Mini Skid Steer
Call for Pricing
Price
Make:
Morbark
Model:
Boxer 700HDX Mini Skid Steer
Category:
Boxer, Morbark
| SPECIFICATION | US | METRIC |
| Engine Type | Kubota | |
| Cooling System | Liquid | |
| HP/kW | 24.8 HP | 18.5 kW |
| Fuel Type | Diesel | |
| Fuel Capacity | 9 Gallons | 34 Litres |
| Hydraulic Capacity | 24 Gallons | 91 Litres |
| System Flow (Total) | 27.1 GPM | 103 L/min |
| Hydraulic Flow Aux (Hi/Lo) | 11.3/8.7 GPM | 43/33 L/min |
| Hydraulic Flow (Drive) | 7.1 GPM | 27 L/min |
| System Pressure | 3000 PSI | 20684 kPa |
| Engine Warranty | 2 years | |
| Product Warranty | 1 year | |
| Track Gauge | 33.75″ | 857 mm |
| Weight (No Attachment) | 2880 lb | 1306 kg |
| Length (No Attachment) | 77″ | 1956 mm |
| Length (w/Bucket) | 96″ | 2438 mm |
| Width (Fully Retracted) | 34.5″ | 876 mm |
| Width (Fully Extended) | 43.5″ | 1105 mm |
| Height (Boom Lowered) | 54″ | 1372 mm |
| Height (Boom Raised) | 98″ | 2489 mm |
| Hinge Pin Height | 77″ | 1956 mm |
| Dump Height | 60″ | 1524 mm |
| Dump Angle | 37 Degrees | |
| Reach | 34″ | 864 mm |
| Tip Capacity | 2020 lb | 915 kg |
| Operating Capacity, 35% of tip load | 707 lb | 320 kg |
| Ground Clearance | 5″ | 127 mm |
| Ground Speed | 4.5 MPH | 7.2 km/h |
| Ground Pressure | 4.21 PSI | 29.7 kPa |
